P1KK006 Retro-Reflex Sensor for Transparent Objects
Kód EXIM-TECH P1KK006
Výrobca: wenglor sensoric
Dostupnosť: V externom sklade
Dokumentácia: PDF
P1KK006 Retro-Reflex Sensor for Transparent Objects
The retro-reflex sensor for clear glass recognition works with red light and a reflector. Where conventional retro-reflex light barriers reach their limits, this retro-reflective barrier for clear glass recognition ensures that extremely shiny objects like glass, PET bottles, trays or film can be detected. Via the single-lens optic without blind spots, the sensor can detect objects even through small holes and gaps. The IO-Link interface can be used to configure retro-reflective barriers (PNP/NPN, NC/NO, switching distance), as well as for reading out switching statuses and signal values.
Kód produktu od výrobcu: P1KK006Kód EXIM-TECH P1KK006
Výrobca: wenglor sensoric
Dostupnosť: V externom sklade
Dokumentácia: PDF
Cenové úrovne
| Množstvo[ks] | Cena bez DPH (Cena s DPH) |
| 1+ | 146.30€ (179.95€ ) |
| 10+ | 136.33€ (163.59€ ) |
| 20+ | Na dopyt |
* Všetky uvedené ceny sú bez DPH (s DPH) a nie je v nich zahrnutá cena dopravy. Doprava bude pripočítaná k objednávke. Informácie o cene dopravy nájdete v sekcii "Doprava a platba". Podrobné informácie o špeciálnych ponukách sú dostupné v „Akcie“.
Pridaj k objednávke
| Optical Data | |
| Range | 1,500mm |
| Switching Hysteresis | <5% |
| Light Source | Red Light |
| Service Life (T = +25 °C) | 100,000h |
| Max. Ambient Light | 10,000Lux |
| Light Spot Diameter | see Table1 |
| Smallest Recognizable Part | see Table2 |
| Reference Reflector/Reflector Foil | RQ100BA |
| Clear Glass Recognition | yes |
| Polarization Filter | yes |
| Single-Lens Optic | yes |
| Reflector data | |
| RQ100BA | 0...1.5m |
| RE18040BA | 0...1.5m |
| RQ84BA | 0...1.5m |
| RR84BA | 0...1.5m |
| RE9538BA | 0...0.7m |
| RE6151BM | 0...1.3m |
| RR50_A | 0...1.5m |
| RE6040BA | 0...1.4m |
| RE8222BA | 0...1m |
| RR34_M | 0...1m |
| RE3220BM | 0...0.6m |
| RE6210BM | 0...0.6m |
| RR25_M | 0...0.7m |
| RR25KP | 0...0.25m |
| RR21_M | 0...0.6m |
| ZRAE02B01 | 0...0.6m |
| ZRME01B01 | 0...0.25m |
| ZRME03B01 | 0...0.65m |
| ZRMR02K01 | 0...0.4m |
| ZRMS02_01 | 0...0.55m |
| RF505 | 0...0.5m |
| RF508 | 0...0.5m |
| RF258 | 0...0.45m |
| ZRDF03K01 | 0...1.1m |
| ZRDF10K01 | 0...1.2m |
| Electrical Data | |
| Supply Voltage | 10...30V DC |
| Current Consumption (Ub = 24 V) | <20mA |
| Switching Frequency | 2,000Hz |
| Response Time | 0.25ms |
| Temperature Drift | <5% |
| Temperature Range | -40...60°C |
| Switching Output Voltage Drop | <2V |
| Residual Current Switching Output | <50µA |
| Reverse Polarity Protection | yes |
| Protection Class | III |
| Supply Voltage With IO-Link | 18...30V DC |
| Switching Output/Switching Current | 100mA |
| Short Circuit And Overload Protection | yes |
| Lockable | yes |
| Interface | IO-Link V1.1 |
| Switching Frequency (speed Mode) | 3,500Hz |
| Response Time (speed Mode) | 0.14ms |
| Mechanical Data | |
| Setting Method | Potentiometer |
| Housing Material | Plastic |
| Degree Of Protection | IP67/IP68 |
| Connection | Cable, 4-wire, 2 m |
| Optic Cover | PMMA |
| Safety-relevant Data | |
| MTTFd (EN ISO 13849-1) | 2,414a |
| Output | |
| IO-Link | yes |
| NPN NO/NC Antivalent | yes |
| Adjustable parameters | |
| Circuit | Inactive Error output NC+NO NO |
| Output | Push-pull NPN PNP |
| Other Parameters | Off-delay On-delay Mode of operation Hysteresis Switching point |
