P1NL412 Retro-Reflex Sensor Universal
Kód EXIM-TECH P1NL412
Výrobca: wenglor sensoric
Dostupnosť: V externom sklade
Dokumentácia: PDF
P1NL412 Retro-Reflex Sensor Universal
The retro-reflex sensor works with a fine laser beam and a reflector. The focused laser class 1 laser beam detects objects, e.g. during assembly, feed or presence checks, from 0.3 mm in size over the entire range. The IO-Link interface can be used to configure retro-reflex sensors (PNP/NPN, NC/NO, switching distance) and to output switching states and signal values.
Kód produktu od výrobcu: P1NL412Kód EXIM-TECH P1NL412
Výrobca: wenglor sensoric
Dostupnosť: V externom sklade
Dokumentácia: PDF
Cenové úrovne
| Množstvo[ks] | Cena bez DPH (Cena s DPH) |
| 1+ | 330.00€ (405.90€ ) |
| 10+ | 307.5€ (369.00€ ) |
| 20+ | Na dopyt |
* Všetky uvedené ceny sú bez DPH (s DPH) a nie je v nich zahrnutá cena dopravy. Doprava bude pripočítaná k objednávke. Informácie o cene dopravy nájdete v sekcii "Doprava a platba". Podrobné informácie o špeciálnych ponukách sú dostupné v „Akcie“.
Pridaj k objednávke
| Optical Data | |
| Range | 5,000mm |
| Switching Hysteresis | <15% |
| Light Source | Laser (red), focused |
| Service Life (T = +25 °C) | 100,000h |
| Max. Ambient Light | 10,000Lux |
| Light Spot Diameter | 1.5mm |
| Laser Class (EN 60825-1) | 1 |
| Smallest Recognizable Part | 0.3mm |
| Reference Reflector/Reflector Foil | RE6151BM |
| Polarization Filter | yes |
| Single-Lens Optic | yes |
| Min. Distance To Reflector | 0mm |
| Focus Distance | 180...220mm |
| Reflector data | |
| RQ100BA | 0...6.5m |
| RE18040BA | 0...4.5m |
| RQ84BA | 0...6m |
| RR84BA | 0...7.8m |
| RE9538BA | 0...2.5m |
| RE6151BM | 0...5m |
| RR50_A | 0...5m |
| RE6040BA | 0...6.7m |
| RE8222BA | 0...3.7m |
| RR34_M | 0...4.2m |
| RE3220BM | 0...3m |
| RE6210BM | 0...1.8m |
| RR25_M | 0...2.6m |
| RR25KP | 0...1.2m |
| RR21_M | 0...1.5m |
| ZRAE02B01 | 0...2.8m |
| ZRME01B01 | 0...1m |
| ZRME03B01 | 0...3.3m |
| ZRMR02K01 | 0...1.3m |
| ZRMS02_01 | 0...1.4m |
| RF505 | 0...1.5m |
| RF508 | 0...1.4m |
| RF258 | 0...1.5m |
| RF255 | 0...1.3m |
| ZRDF03K01 | 0...5m |
| ZRDF10K01 | 0...4.4m |
| ZRAF07K01 | 0...1.3m |
| ZRAF08K01 | 0...1.5m |
| RF4050 | 0...1.2m |
| Z90R004 | 0.15...2.6m |
| Z90R005 | 0.15...3.6m |
| Z91R001 | 0...4.2m |
| Electrical Data | |
| Supply Voltage | 10...30V DC |
| Current Consumption (Ub = 24 V) | <20mA |
| Switching Frequency | 5,000Hz |
| Response Time | 0.1ms |
| Temperature Drift | <10% |
| Temperature Range | -25...60°C |
| Switching Output Voltage Drop | <2V |
| Residual Current Switching Output | <50µA |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Overload Protection | yes |
| Protection Class | III |
| Supply Voltage With IO-Link | 18...30V DC |
| Switching Output/Switching Current | 100mA |
| FDA Accession Number | 1911373-000 |
| On-Delay | 20ms |
| Mechanical Data | |
| Setting Method | Potentiometer |
| Housing Material | Plastic |
| Degree Of Protection | IP67/IP68 |
| Connection | M12 × 1; 4-pin |
| Optic Cover | PMMA |
| Safety-relevant Data | |
| MTTFd (EN ISO 13849-1) | 2,369.59a |
| Output | |
| PNP NC | yes |
| Adjustable parameters | |
| Circuit | NC NC/NO NO |
| Output | Push-pull NPN PNP |
| Other Parameters | Off-delay On-delay Mode of operation Hysteresis Emitted light |
