P1KL014 Retro-Reflex Sensor Universal
Kód EXIM-TECH P1KL014
Výrobca: wenglor sensoric
Dostupnosť: V externom sklade
Dokumentácia: PDF
P1KL014 Retro-Reflex Sensor Universal
The retro-reflex sensor works with a fine laser beam and a reflector. The collimated laser beam of laser class 1 detects objects, for instance, when conducting installation, feed or presence controls, starting at a size of one millimeter over the entire range. The IO-Link interface can be used to configure retro-reflective barriers (PNP/NPN, NC/NO, switching distance), as well as for reading out switching statuses and signal values.
Kód produktu od výrobcu: P1KL014Kód EXIM-TECH P1KL014
Výrobca: wenglor sensoric
Dostupnosť: V externom sklade
Dokumentácia: PDF
Cenové úrovne
| Množstvo[ks] | Cena bez DPH (Cena s DPH) |
| 1+ | 179.30€ (220.54€ ) |
| 10+ | 167.08€ (200.49€ ) |
| 20+ | Na dopyt |
* Všetky uvedené ceny sú bez DPH (s DPH) a nie je v nich zahrnutá cena dopravy. Doprava bude pripočítaná k objednávke. Informácie o cene dopravy nájdete v sekcii "Doprava a platba". Podrobné informácie o špeciálnych ponukách sú dostupné v „Akcie“.
Pridaj k objednávke
| Optical Data | |
| Range | 12,000mm |
| Switching Hysteresis | <15% |
| Light Source | Laser (red), collimated |
| Service Life (T = +25 °C) | 100,000h |
| Max. Ambient Light | 10,000Lux |
| Light Spot Diameter | see Table1 |
| Wave length | 655nm |
| Laser Class (EN 60825-1) | 1 |
| Smallest Recognizable Part | see Table2 |
| Reference Reflector/Reflector Foil | RE6151BM |
| Polarization Filter | yes |
| Two-Lens Optic | yes |
| Reflector data | |
| RQ100BA | 0.1...16m |
| RE18040BA | 0.1...12m |
| RQ84BA | 0.1...16m |
| RR84BA | 0.1...16m |
| RE9538BA | 0.1...4.5m |
| RE6151BM | 0.1...12m |
| RR50_A | 0.1...16m |
| RE6040BA | 0.1...15m |
| RE8222BA | 0.1...10m |
| RR34_M | 0.1...2.5m |
| RE3220BM | 0.1...7m |
| RE6210BM | 0.1...4.5m |
| RR25_M | 0.1...7m |
| RR25KP | 0.1...2.5m |
| RR21_M | 0.1...4m |
| ZRAE02B01 | 0.1...7m |
| ZRME01B01 | 0.1...3m |
| ZRME03B01 | 0.1...4.5m |
| ZRMR02K01 | 0.1...3m |
| ZRMS02_01 | 0.1...4m |
| RF505 | 0.1...2m |
| RF508 | 0.1...2m |
| RF258 | 0.1...2m |
| ZRDF03K01 | 0.1...4m |
| ZRDF10K01 | 0.1...4m |
| Z90R004 | 0.15...5m |
| Z90R005 | 0.15...5.9m |
| Electrical Data | |
| Supply Voltage | 10...30V DC |
| Current Consumption (Ub = 24 V) | <15mA |
| Switching Frequency | 2,000Hz |
| Response Time | 0.25ms |
| Temperature Drift | <10% |
| Temperature Range | -40...60°C |
| Switching Output Voltage Drop | <2V |
| Residual Current Switching Output | <50µA |
| Reverse Polarity Protection | yes |
| Protection Class | III |
| Supply Voltage With IO-Link | 18...30V DC |
| Switching Output/Switching Current | 100mA |
| Short Circuit And Overload Protection | yes |
| Lockable | yes |
| Interface | IO-Link V1.1 |
| FDA Accession Number | 1710976-001 |
| Switching Frequency (speed Mode) | 4,000Hz |
| Response Time (speed Mode) | 0.125ms |
| Mechanical Data | |
| Setting Method | Potentiometer |
| Housing Material | Plastic |
| Degree Of Protection | IP67/IP68 |
| Connection | M8 × 1; 4-pin |
| Optic Cover | PMMA |
| Safety-relevant Data | |
| MTTFd (EN ISO 13849-1) | 2,617.62a |
| Output | |
| IO-Link | yes |
| NPN NO/NC Antivalent | yes |
| Adjustable parameters | |
| Circuit | NC NO Inactive Error output NC+NO |
| Output | Push-pull NPN PNP |
| Other Parameters | Off-delay On-delay Mode of operation Hysteresis Emitted light Switching point |
