7356-74641-7940100 RJ45 Push Pull male 0°/ RJ45 Push Pull male 0°
Kód EXIM-TECH 7356-74641-7940100
Výrobca: Murrelektronik
Dostupnosť: V externom sklade
Dokumentácia: PDF
7356-74641-7940100 RJ45 Push Pull male 0°/ RJ45 Push Pull male 0°
PUR 1x4xAWG22 shielded gn UL/CSA 1m
Kód produktu od výrobcu: 7356-74641-7940100Kód EXIM-TECH 7356-74641-7940100
Výrobca: Murrelektronik
Dostupnosť: V externom sklade
Dokumentácia: PDF
Cenové úrovne
| Množstvo[ks] | Cena bez DPH (Cena s DPH) |
| 1+ | 96.26€ (118.40€ ) |
| 10+ | 98.35€ (118.02€ ) |
| 20+ | Na dopyt |
* Všetky uvedené ceny sú bez DPH (s DPH) a nie je v nich zahrnutá cena dopravy. Doprava bude pripočítaná k objednávke. Informácie o cene dopravy nájdete v sekcii "Doprava a platba". Podrobné informácie o špeciálnych ponukách sú dostupné v „Akcie“.
Pridaj k objednávke
Male straight, Push Pull RJ45
4-pole
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Further cable lengths on request.
4-pole
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Further cable lengths on request.
| Technical Data | |
| No. Of Poles | 4 |
| Operating Voltage | max. 60 V DC |
| Operating Current Per Contact | max. 1.76 A |
| Protection | IP65/IP67 inserted and tightened (EN 60529) |
| LED Display | no |
| Material Group | IEC 60664-1, category I |
| Transfer Parameters | CAT5, Class D (ISO/IEC 11801) |
| Rated Surge Voltage | 1.0 kV |
| Suitable For Corrugated Tube (internal Ø) | 10 mm |
| Operating Voltage (only UL Listed) | max. 30 V DC |
| Commercial data | |
| Country Of Origin | DE |
| Customs Tariff Number | 85444210 |
| EAN | 4048879840118 |
| EClass | 27279218 |
| Packaging Unit | 1.000 |
| Cables | |
| Cable Identification | 794 |
| Approval (cable) | cURus (AWM-Style 20549/10578), CE-conform |
| Cable Weight [g/m] | 75,87 g |
| Material (wire) | Cu wire, bare |
| Resistor (core) | max. 55 Ω/km (20 °C) |
| Construction (core) | 7× 0.254 mm |
| Diameter (core) | 1× 4× AWG22/7 |
| AWG | similar to AWG 22 |
| Material (wire Isolation) | PE |
| Wire-Ø Incl. Isolation | 1.55 mm ±5% |
| Color/numbering Of Wires | wh, ye, bl, or |
| Shield | yes |
| Material (jacket) | PUR |
| Outer-Ø (jacket) | 6.7 mm ±5% |
| Color (jacket) | green |
| Chemical Resistance | Oil resistance according to IEC 60811-2-1, ASTM IRM 901, ICEA S-82-552 Std. |
| Nominal Voltage | 300 V |
| Temperature Range (fixed) | -40...+80 °C |
| Temperature Range (mobile) | -30...+70 °C |
| Bend Radius (fixed) | 6× outer Ø |
| Bend Radius (moving) | 12× outer Ø |
| Optical Shield Cover | min. 85% |
| Thermal Resistance | flame-retardant according to UL 1581 section 1090, section 1100 (FT2), IEC 60332-1-2 Std. |
| Form | |
| Form | 74641 |
| General data | |
| Mounting Method | pluggable |
| Temperature Range | -25...+85 °C, depending on cable quality |
| Material (contact) | Copper alloy |
| Pollution Degree | 3 |
